HZ432K
 4 zone  Kit with transformer, discharge air sensor
$336.66

Overview

TrueZONE® HZ432 Panel for conventional, heat pump or dual fuel applications expandable up to 32 zones (3H/2C)

Features

  • Intuitive Installer setup. Easy-to-follow, digital display uses real language to guide installer through four easy steps.
  • Standard Checkout Procedure
  • Robust Push Terminals
  • Common-Sense LEDs
  • Clean, Professional Installation
  • Variable-Speed Fan Control
  • Discharge Air Temperature Staging
  • Advanced Dual-Fuel Operation
  • Use with TAZ-4 Add-A-Zone to expand to 32 zones
  • RedLINK™ enabled for up to 4 wireless zones when used with THM4000R1000 Wireless Adapter



Product Specifications

Application
Zoning
Includes
HZ432 Zone Control Panel, AT140 Transformer, C7735A Discharge Air Temperature Sensor
Stages
3 Heat/2 Cool
Number of Zones
4 Zone, Expandable
Voltage
24V
LEDs
Yes
Network Zoning
No
Auto Changeover
Yes
Heat Pump Compatible
Yes
Compatible with Sensor
Discharge Air Temperature Sensor
Emergency Heat Switch
Yes
Resettable Fuse
Yes
Individual Zone Fan Control
Yes

HZ322K
3 Zone Kit with transformer, discharge air sensor
$208.57

Overview

TrueZONE® HZ322 Panel for conventional and heat pump applications up to 3 zones (2H/2C).

Features

  • Intuitive Installer setup. Easy-to-follow, digital display uses real language to guide installer through four easy steps.
  • Standard Checkout Procedure
  • Robust Push Terminals
  • Common-Sense LEDs
  • Clean, Professional Installation
  • Smaller Footprint
  • Variable-Speed Fan Control
  • Discharge Air Temperature Staging
  • RedLINK™ enabled for wireless operation when used with THM4000R1000 wireless adapter

Product Specifications

Application
Zoning
Includes
HZ322 Zone Control Panel, AT140 Transformer, C7735A Discharge Air Temperature Sensor
Stages
2 Heat/2 Cool
Number of Zones
3 Zone
Voltage
24V
LEDs
Yes
Network Zoning
No
Auto Changeover
Yes
Heat Pump Compatible
Yes
Compatible with Sensor
Discharge Air Temperature Sensor
Emergency Heat Switch
Yes
Resettable Fuse
Yes
Individual Zone Fan Control
Yes

YTH6320R1023
 Wireless zoning adapter kit
$159.68

Overview

Everything you need to relocate or upgrade with a programmable thermostat without running new wires. Kit options include wireless outdoor sensors, RedLINK Internet Gateway for remote access, or wireless adapters for working with TrueZONE panels

Features

  • WIRELESS FOCUSPRO® THERMOSTAT: Same great features of the FocusPRO® thermostat - now wireless. Installs in minutes. Displays outdoor temperature and humidity. 1 year battery life. 2 month low battery warning. Dual Fuel enabled.
  • EQUIPMENT INTERFACE MODULE(EIM): All HVAC equipment is wired to the module. Module receives communication from the wireless devices.
  • RETURN AIR SENSOR: Works with the Equipment Interface Module to maintain safe indoor temperatures if power is lost at the wireless thermostat. Maintains 62 F for heating and 82 F for cooling.
  • REDLINK™ WIRELESS TECHNOLOGY: Powered by RedLINK™ reliability. No interference with other wireless devices in the home.

Product Specifications

Application
Heat Pump Systems; Forced warm air
Includes
TH6320R1004 Wireless FocusPRO® 5-1-1 Programmable Thermostat; THM4000R1000 Wireless Adapter
Switch Positions (System)
HEAT-OFF-COOL-AUTO-EM.HEAT
Switch Positions (Fan)
AUTO-ON
Programmability
5-1-1 Day Program or 5-2 Day Program
Power Method
Thermostat--Battery
Changeover
Auto/Manual Selectable

TH6320R1004
 Programmable stat for extra wireless zones
$135.18


Overview

Honeywell’s FocusPRO® 6000 digital thermostat offers the perfect blend of features, performance, energy savings and value. With the largest backlit screen in its class, the FocusPRO 6000 prominently displays both room and set temperature.

Features

  • Selectable to 5-1-1 (Weekdays, Saturday, Sunday) or 5-2 (Weekdays, Weekend) programmable thermostat.
  • Large, clear, backlit display - easy to read in various lighting conditions.
  • Display size options - available in large screen or standard.
  • Precise comfort control (+/-1 F) - maintains consistent comfort to the highest level of accuracy.
  • Simplified programming and operation.
  • Easy change battery door - flip out door allows for easy battery replacement without removing or disassembling the thermostat.
  • Built in instructions - simple, pull out instruction manual.
  • Adaptive Intelligent Recovery™ - ensures programmed temperature is reached by programmed time.
  • Temperature range stops - prevents user from setting the temperature too high or too low.

Product Specifications

Application
Gas, oil, electric, heat pump, forced warm air, hot water, steam or gravity
Dimensions (in.)
3 9/16 in. High X 5 13/16 in. Wide X 1 1/2 in. Deep
Dimensions (mm)
91 mm High X 147 mm Wide X 38 mm Deep
Comments
Thermostat is also available in kits for zoned and non-zoned systems
Mounting
Horizontal
Stages
Up to 3 Heat / 2 Cool Heat Pump or Up to 2 Heat / 2 Cool Conventional
Operating Humidity Range (% RH)
5 to 90% RH, non-condensing
Switch Positions (System)
HEAT-OFF-COOL-AUTO-EM.HEAT
Switch Positions (Fan)
AUTO-ON
Operating Temperature Range (F)
32 F to 120 F
Operating Temperature Range (C)
0 C to 48.9 C
Sensor Element
Thermistor
Differential Temperature (F)
± 1 F
Differential Temperature (C)
±0.5 C
Color
Premier White®
Programmability
5-1-1 Day Program or 5-2 Day Program
Power Method
Battery
Changeover
Auto/Manual Selectable
Setting Temperature Range (F)
Heat: 40 F to 90 F; Cool: 50 F to 99 F
Setting Temperature Range (C)
Heat: 4.5 C to 32 C; Cool: 10 C to 37 C
Parts Needed for Operation (not included) - TrueZONE™ System
HZ432 or HZ322 TrueZONE™ panel; THM4000R1000 Wireless Adapter
Parts Needed for Operation (not included) - Non-Zoned System
THM5320R1000 Equipment Interface Module


YTH5320R1025 Wireless Zoning adapter Kit
 gets stat TH5320R1002 Non program stat and wireless adapter


Overview

Everything you need to relocate or upgrade with a non-programmable thermostat without running new wires. Kit options include wireless outdoor sensor, RedLINK Internet Gateway for remote access, or wireless adapters for working with TrueZONE panels.

Features

  • WIRELESS FOCUSPRO® THERMOSTAT: Same great features of the FocusPRO® thermostat - now wireless. Installs in minutes. Displays outdoor temperature and humidity. 1 year battery life. 2 month low battery warning. Dual Fuel enabled.
  • EQUIPMENT INTERFACE MODULE (EIM): All HVAC equipment is wired to the module. Module receives communication from the wireless devices.
  • RETURN AIR SENSOR: Works with the Equipment Interface Module to maintain safe indoor temperatures if power is lost at the wireless thermostat. Maintains 62 F for heating and 82 F for cooling.
  • REDLINK™ WIRELESS TECHNOLOGY: Powered by RedLINK™ reliability. No interference with other wireless devices in the home.

Product Specifications

Application
Heat Pump Systems; Forced warm air
Includes
TH5320R1002 Wireless FocusPRO® Non-Programmable Thermostat; THM4000R1000 Wireless Adapter
Switch Positions (System)
HEAT-OFF-COOL-AUTO-EM.HEAT
Switch Positions (Fan)
AUTO-ON
Power Method
Thermostat--Battery
Changeover
Auto/Manual Selectable


YTH5320R1025 Wireless Zoning adapter Kit

$143.69


TH5320R1002 Non Programmable stat for extra wireless zones
$118.18

Overview

Honeywell’s FocusPRO® 5000 digital thermostat offers the perfect blend of features, performance, energy savings and value. With the largest backlit screen in its class, the FocusPRO 5000 prominently displays both room and set temperature.

Product Specifications

Application
Gas, oil, electric, heat pump, forced warm air, hot water, steam or gravity
Dimensions (in.)
3 9/16 in. High X 5 13/16 in. Wide X 1 1/2 in. Deep
Dimensions (mm)
91 mm High X 147 mm Wide X 38 mm Deep
Comments
Thermostat is also available in kits for zoned and non-zoned systems
Mounting
Horizontal
Stages
Up to 3 Heat / 2 Cool Heat Pump or Up to 2 Heat / 2 Cool Conventional
Operating Humidity Range (% RH)
5 to 90% RH, non-condensing
Switch Positions (System)
HEAT-OFF-COOL-AUTO-EM.HEAT
Switch Positions (Fan)
AUTO-ON
Operating Temperature Range (F)
32 F to 120 F
Operating Temperature Range (C)
0 C to 48.9 C
Sensor Element
Thermistor
Differential Temperature (F)
± 1 F
Differential Temperature (C)
±0.5 C
Color
Premier White®
Power Method
Battery
Changeover
Auto/Manual Selectable
Setting Temperature Range (F)
Heat: 40 F to 90 F; Cool: 50 F to 99 F
Setting Temperature Range (C)
Heat: 4.5 C to 32 C; Cool: 10 C to 37 C
Parts Needed for Operation (not included) - TrueZONE™ System
HZ432 or HZ322 TrueZONE™ panel; THM4000R1000 Wireless Adapter
Parts Needed for Operation (not included) - Non-Zoned System
THM5320R1000 Equipment Interface Module




YTH6320R1001
Wireless program stat and Equipment module for wireless control to non Honeywell panels and HVAC equipment.


Overview

Everything you need to relocate or upgrade with a programmable thermostat without running new wires. Kit options include wireless outdoor sensors, RedLINK Internet Gateway for remote access, or wireless adapters for working with TrueZONE panels

Features

  • WIRELESS FOCUSPRO® THERMOSTAT: Same great features of the FocusPRO® thermostat - now wireless. Installs in minutes. Displays outdoor temperature and humidity. 1 year battery life. 2 month low battery warning. Dual Fuel enabled.
  • EQUIPMENT INTERFACE MODULE(EIM): All HVAC equipment is wired to the module. Module receives communication from the wireless devices.
  • RETURN AIR SENSOR: Works with the Equipment Interface Module to maintain safe indoor temperatures if power is lost at the wireless thermostat. Maintains 62 F for heating and 82 F for cooling.
  • REDLINK™ WIRELESS TECHNOLOGY: Powered by RedLINK™ reliability. No interference with other wireless devices in the home.

Product Specifications

Application
Gas, oil, electric, heat pump, forced warm air, hot water, steam or gravity
Includes
C7735A1000 Return Air Sensor; THM5320R1000 Equipment Interface Module; TH6320R1004 Wireless FocusPRO® 5-1-1 Programmable Thermostat
Electrical Ratings
Equipment Interface Module--18 to 30 Vac, 50 Hz; 60 Hz
Stages
Up to 3 Heat / 2 Cool Heat Pump or Up to 2 Heat / 2 Cool Conventional
Switch Positions (System)
HEAT-OFF-COOL-AUTO-EM.HEAT
Switch Positions (Fan)
AUTO-ON
Programmability
5-1-1 Day Program or 5-2 Day Program
Power Method
Thermostat--Battery
Terminal Designations
C, R, Rc, Rh, W-O/B, W2-Aux/E, Y, Y2, G, L, RAS
Changeover
Auto/Manual Selectable
Cool Current
1.0 A running
Heat Current
1.0 A running
Fan Current
0.6 A running



YTH6320R1001 Wireless program stat and Equipment module

$225.85
